Bottle-top dispensers

Calibrex^™
solutae 530 bottle-top dispenser

Instrument comparison

Ordering information

Calibrex^TM solutae 530 Bottle-top dispensers

Ordering information

Volume	Division	Cat. No. Without Stopcock	Cat. No. With Stopcock
0.1 - 1 mL	0.02 mL	530.001	530.001FC
0.25 - 2.5 mL	0.05 mL	530.002.5	530.002.5FC
0.5 - 5 mL	0.1 mL	530.005	530.005FC
1 - 10 mL	0.2 mL	530.010	530.010FC
2.5 - 25 mL	0.5 mL	530.025	530.025FC
5 - 50 mL	1.0 mL	530.050	530.050FC
10 - 100 mL	1.0 mL	530.100	530.100FC
Base thread 45 mm. Supplied with feed tubing, delivery jet with stopper, bottle neck adapters, QC certificate and operating instructions. Sizes 1 and 2.5 mL - 300 mm feed tubing - 90 mm delivery jet - 25, 28 and 32 mm adapters Sizes 5 and 10 mL - 300 mm feed tubing - 90 mm delivery jet - 28, 32 and 40 mm adapters As of 25 mL - 350 mm feed tubing - 120 mm delivery jet - 32, 38 and 40 mm adapters

Performance information

Calibrex^TM solutae 530 Bottle-top dispensers

Performance information

Volume		Inaccuracy (E%)			Imprecision (CV%)
Range	Division	Min. vol.	Mid. vol.	Max. vol.	Min. vol.	Mid. vol.	Max. vol.
0.1 - 1 mL	0.02 mL	<± 3.0 %	<± 1.8 %	<± 0.6 %	< 1.2 %	< 0.7 %	< 0.17 %
0.25 - 2.5 mL	0.05 mL	<± 2.7 %	<± 1.6 %	<± 0.6 %	< 0.9 %	< 0.55 %	< 0.17 %
0.5 - 5 mL	0.1 mL	<± 2.0 %	<± 1.3 %	<± 0.6 %	<± 0.5 %	<± 0.35 %	<± 0.1 %
1 - 10 mL	0.2 mL	<± 1.5 %	<± 1.2 %	<± 0.6 %	<± 0.5 %	<± 0.35 %	<± 0.1 %
2.5 - 25 mL	0.5 mL	<± 1.5 %	<± 1.1 %	<± 0.6 %	<± 0.5 %	<± 0.35 %	<± 0.1 %
5 - 50 mL	1.0 mL	<± 1.5 %	<± 1.1 %	<± 0.6 %	<± 0.5 %	<± 0.35 %	<± 0.1 %
10 - 100 mL	1.0 mL	<± 1.5 %	<± 1.1 %	<± 0.6 %	<± 0.5 %	<± 0.35 %	<± 0.1 %
Performance values obtained with bidest water at constant temperature (± 0.5°C) comprised between 20 and 25°C, according to EN ISO 8655. Omission to untighten connecting body ring before autoclaving, and / or over-tightening ring when dispensing, may reduce performance.

Description

A generation of robust instruments with excellent chemical resistance, high performance and easy maintenance. This bottle-top dispenser has glas or ceramic PFA coated plunger, preventing crystallization of chemicals. Fitting most reagent bottles, it enables safe and reproducible dispensing in volumes ranging from 1 to 100 mL. Two-year warranty.

PFA coated plunger
Best for acids, bases and salt solutions
Permanent fluid path visibility
Integrated calibration system
Choice of adjustement button (optional)
Flow control system with stopcock (optional)
QR code accessing compatibility chart
Autoclavable at 121°C / 250°F fully assembled

Check the organo version for handling organic solvents.

Model Selection

0.1 - 1 mL
0.25 - 2.5 mL

0.5 - 5 mL
1 - 10 mL

2.5 - 25 mL
5 - 50 mL

10 - 100 mL

Highlights

Volume setting and graduation scale
Robustness
Transparent sleeve
Optimal working position
Flexible connection
Air filter
In-lab calibration
Time efficient maintenance
QR coded chemical compatibility
Environment and sustainability

Videos & Documents

General presentation

Calibrex^TM Bottle-top dispensers

Catalog / Leaflet

Download

Calibrex^TM solutae 530

Operating Instruction

Download

Calibrex^TM 525/530
Bottle-top dispensers

Chemical Resistance Chart

Download

Models

Accessories

Find your distributor

Find a distributor

Service & Calibration

Contact the Socorex Service & Calibration center for maintenance and calibration.

Learn more

Differentiating features	Calibrex^TM solutae 530	Calibrex^TMorgano 525	Calibrex^TMuniversal 520
Volume range	7 models from 0.1 to 100 mL	7 models from 0.1 to 100 mL	3 models from 0.25 to 10 mL
Volume setting	Sliding cursor along double scale	Sliding cursor along double scale	Setting ring, display window
Plunger	PFA coated, optimal for acids, bases and salt solutions	Ground glass, ideal for organic solvents	PFA coated, universal chemical resistance
Stopcock	Available in option	Available in option	No
Calibration	Instant calibration with integrated key	Instant calibration with integrated key	Instant calibration with integrated key
Fixed volume	No	No	Yes
